Sonda Navico 12568 TotalScan Skimmer Mid/High/StructureScan
125,00 EUR
TotalScan™ Skimmer Mid/High/StructureScan
Part Number: 000-12568-001
- 7 pin
- Za Lowrance i Simrad
- CHIRP, DownScan™ Imaging and StructureScan™ HD into one package.
- Fully compatible with Lowrance HDS Gen3, Elite-7Ti, Elite-5Ti, Simrad NSS evo2, and NSO evo2 via SonarHub Sounder Module
The New TotalScan™ Skimmer Transducer combines the proven technology of CHIRP, DownScan™ Imaging and StructureScan™ HD into one package.
The TotalScan™ Skimmer Transducer will now allow anglers to access Medium CHIRP, High CHIRP, DownScan™ Imaging and StructureScan™ using only a single transducer mounted to the transom, jackplate or a flat surface (appropriate mounting brackets required based on mounting location).
Key Features
- All-in-one transducer featuring Broadband, CHIRP, StructureScan HD and DownScan Imaging™
- Supports 83/200kHz Broadband sonar frequencies
- Supports Medium and High CHIRP frequencies
- Supports 455/800kHz StructureScan® frequencies
- Supports Water Temperature
- Multiple mounting options
Availability:
In stock
SKU
Sonda Navico 12568 TotalScan Skimmer Mid/High/StructureScan
Overview
General
- Transmit Power: N/A
- Transducer Frequencies: 83/200/455/800 kHz, Medium/High CHIRP
- Sonar: SideScan Imaging
SideScan Imaging
- Max Range:
455 kHz – 600’ (182 m), 300’ (91 m) to each side;
800 kHz – 200’ (60 m), 100’ (30 m) to each side - Max Speed: 35 mph (56 kph)
- Mark Objects: 15 mph (24 kph)
- Optimum Speed: 10 mph (16 kph) or less
DownScan Imaging™
- Max Depth: 300’ (92 m)
- Max Speed: 55 mph (88 kph)
- Mark Objects: 35 mph (56 kph)
- Optimum Speed: 10 mph (16 kph) or less
Technical / Environmental
- Product Width: 2.3” (59.2 mm)
- Product Length: 10.2” (259 mm)
Networking Connectors
- Connectors: xSonic (9-pin)
Other
- Cable: 24’ (7.3 m)
