Sonda Airmar® P66 TRIDUCER® Multisensor

Part No: 000-13919-001

Features

• Depth, speed, and temperature in one housing
• Plastic kick-up bracket
• Accommodates transom angles between 2° and 20°
• Recessed waterflow channel protects paddlewheel
• Transducer can be removed from bracket without the use of tools for easy service and storage
• Boat Size: Up to 12 m (40’)
• Exclusive Xducer ID® technology

Specifications

• Weight: 0.5 kg (1.1 lb)
• Hull Deadrise: 2° to 20°
• Acoustic Window: Layered plastic urethane

Detailed Description

The P66 TRIDUCER® Multisensor features our 50/200 kHz, dual-frequency, single-ceramic element. This hydrodynamic housing with a rounded nose reduces the turbulence under the transducer’s face for accurate high-speed readings and clear display images.

...........................................................................................................................................................

P66



P66 TRIDUCER® Multisensor/CW Transom-Mount

600 W

The P66 TRIDUCER® Multisensor transom-mount features our 50/200 kHz, dual-frequency, single ceramic element. This hydrodynamic housing with a rounded nose reduces the turbulence under the transducer’s face for accurate high speed readings and clear display images.



Features



• Depth, speed, and temperature
• 600 W
• Dual-frequency elements:
  • 50 kHz to 45° beamwidth with depth performance to 353 m (1200')
  • 200 kHz to 12° beamwidth with depth performance to 206 m (700')
• Recessed waterflow channel protects paddlewheel from obstructions
• Transducer can be removed from bracket without the use of tools for easy service and storage
• Plastic kick-up bracket protects transducer in case of obstructions
• Recommended boat size: Up to 12 m (40')

Specifications



• Weight: 0.5 kg (1.1 lb)
• Accommodates transom angles between 2° to 22°
• Acoustic Window: Layered plastic urethane (LPU)
• Operating speed: Up to 44 knots (50 mph)
